• sintered clutch button

FXL 2 Vertical holes

FXL Copper  Clutch Button
Dimension:63x57mm, 2 vertical holes;
Thickness: 4.0mm-4.8mm;
Both smooth and rough surface available.

FXL is our copper clutch friction material used in small type of clutch disc assembly. The sintered clutch button has a low friction coefficient and longer life. We have three clutch button formula currently, one is our regular formula, smooth finish and medium property, another is the low wear formula with rough finish, the third one is a new formula, it’s developed with the assistance of the oversea engineer, and this button is following Miba appearance and similar to its finish and property, it is supplied to our OE customers, due to its low cost and excellent property, it is very popular among our customers from South America and India.

FRICWEL NO. DESCRIPTION DIMENSION
(mm)
WELLMAN WELLMAN THICKNESS MIBA MIBA THICKNESS
INCH MM INCH MM
FXL 140.360 2 Vertical holes 63X57 VT-4 0.140 3.556 BV 140.360 0.140 3.556
FXL 156.400 VT-5 0.156 3.962 BV 156.400 0.156 3.962
FXL 173.440 VT-7 0.178 4.521 BV 173.440 0.173 4.394
FXL 187.480 VT-8 0.187 4.750 BV 187.480 0.187 4.750
